Dynabrade 52538 3″ (76mm) Dia. Right Angle Cut-Off Wheel Tool, Central Vacuum

MRP: £944.82

£752.05 +VAT

Go to Parts Manual

Dynabrade 52538 3″ (76mm) Dia. Right Angle Cut-Off Wheel Tool, Central Vacuum


FINANCE OPTIONS AVAILABLE

PAY FROM £20.77 PER MONTH

Description

Product Description of Dynabrade 52538 3" (76mm) Dia. Right Angle Cut-Off Wheel Tool, Central Vacuum

• Vacuum Cut-Off Wheel Tool, for efficient cutting with dust and debris removal.
• 3" Diameter, Right Angle, .4 hp, 12,000 RPM, Rear Exhaust. Ideal for use with optional 3" diameter Diamond Cut-Off Wheels.
• Adjustable wheel guard has vacuum port (1" outside diameter) that diverts airborne dust and debris to optional vacuum source.
• Non-marring composite base is removable to utilize maximum blade depth of 11/16". Optional 52646 composite base is available for gel coat notching.
• Dual-wick lubrication system saturates gears with oil for increased performance, extended life and reduced downtime. Safety-lock lever is included.

Parts Manuals for the Dynabrade 52538 3" (76mm) Dia. Right Angle Cut-Off Wheel Tool, Central Vacuum

Find the five digit number for your part(s) in the parts manual below, and click the link to open a new tab where you can add it to your basket. Please note that depending on the age of your tool this may not be the correct parts manual - it should however state the range of serial numbers to which it applies at the top left/right of the first page.

Current Manual

Tune-Up Kit

Book a Dynabrade Repair

If you would like to book a repair for the Dynabrade 52538 3" (76mm) Dia. Right Angle Cut-Off Wheel Tool, Central Vacuum please use the form below. You will then receive an email - simply place a copy of this email in the box with your tool and send it to the address stated in the email.

Vibration & Sound Readings for the Dynabrade 52538 3" (76mm) Dia. Right Angle Cut-Off Wheel Tool, Central Vacuum

Please note – The vibration readings provided for the Dynabrade 52538 3" (76mm) Dia. Right Angle Cut-Off Wheel Tool, Central Vacuum are based on laboratory results in very specific sets of conditions. Vibration levels are dependent on a number of factors that include, among many others; the abrasive being used, the job in hand and operator experience. DynaShop or Dynabrade cannot be held responsible for the consequences of using the listed values for risk assessment, rather than real-world values measured in your own specific application.

Vibration Level EN1296 (m/sec²)Uncertainty EN1296 (m/sec²)Vibration Test Method
Under 2.50.3S1049

Sound Pressure (dBA)Sound Power (dBA)
8495

Would you like this data in an email?

Simply fill out the form below and the vibration data for the Dynabrade 52538 3" (76mm) Dia. Right Angle Cut-Off Wheel Tool, Central Vacuum will be sent to your email automatically.

On-Site Tool Demonstrations of the Dynabrade 52538 3" (76mm) Dia. Right Angle Cut-Off Wheel Tool, Central Vacuum

Please complete the form below to arrange a tool demonstration for the Dynabrade 52538 3" (76mm) Dia. Right Angle Cut-Off Wheel Tool, Central Vacuum or any of the Dynabrade range of tooling. Alternatively please call us on 01273 468736.

Book a Tool Demonstration

    For our privacy policy please click here.

Video of the Dynabrade 52538 3" (76mm) Dia. Right Angle Cut-Off Wheel Tool, Central Vacuum

Additional information

Tool Type

Model Number

52538

Air Inlet Thread

1/4" NPT

Vacuum Type

Max. RPM

Exhaust Type

Power HP (W)

Consumable Shape

Consumable Size

Item Weight (kgs)

Packaged Weight (kgs)

Other Specifications

, , , , , ,

Vibration Level (m/sec²)

Uncertainty

Vibration Method

Sound Pressure (dBA)

Sound Power (dBA)
