Product Description of Dynabrade 52638 4-1/2" (114mm) Dia. Right Angle Depressed Center Wheel Grinder
• 1.3 hp Depressed Center Wheel Grinder is ideal for fast weld and stock removal, heavy deburring, plus rust and scale removal.
• 12,000 RPM, M14 x2 Spindle Thread.
• Tool accepts optional 115 mm (4-1/2") diameter Type 27 Depressed Center Wheels with 22 mm (7/8") center hole.
• Includes 25215 Wheel Guard, 25262 Backup Flange and 53696 Locking Flange.
The Dynabrade 52638 4-1/2" (114mm) Dia. Right Angle Depressed Center Wheel Grinder is a Dynabrade tool within the Grinder category of tooling range. Depressed Center Wheels of 114mm can be used which can also be supplied by DynaShop. A Non-Vacuum tool with a maximum RPM of 12000, a power rating (hp/W) of 1.3 (970) with a weight of 2.45kg.
Parts Manuals for the Dynabrade 52638 4-1/2" (114mm) Dia. Right Angle Depressed Center Wheel Grinder
Find the five digit number for your part(s) in the parts manual below, and click the link to open a new tab where you can add it to your basket. Please note that depending on the age of your tool this may not be the correct parts manual - it should however state the range of serial numbers to which it applies at the top left/right of the first page.
Current Manual
Tune-Up Kit
Book a Dynabrade Repair
Vibration & Sound Readings for the Dynabrade 52638 4-1/2" (114mm) Dia. Right Angle Depressed Center Wheel Grinder
Important Notice:
The vibration and sound readings provided for the Dynabrade 52638 4-1/2" (114mm) Dia. Right Angle Depressed Center Wheel Grinder are based on laboratory testing carried out under controlled conditions.
Actual levels in use can vary significantly depending on factors such as the abrasive material, application, tool maintenance, and operator technique.
These figures should therefore be used as a guideline only. DynaShop and Dynabrade accept no liability for any decisions or assessments made using the listed data instead of measurements taken under your specific operating conditions.
| Vibration Level EN1296 (m/s²) | Uncertainty EN1296 (m/s²) | Vibration Test Method |
|---|---|---|
| Under 2.5 | 1.6 | ISO 8662-4 |
| Sound Pressure (dBA) | Sound Power (dBA) |
|---|---|
| 78 | 89 |
Would you like this data emailed to you?
Fill out the form below and we’ll send the vibration and sound data for the Dynabrade 52638 4-1/2" (114mm) Dia. Right Angle Depressed Center Wheel Grinder directly to your inbox.
On-Site Tool Demonstrations of the Dynabrade 52638 4-1/2" (114mm) Dia. Right Angle Depressed Center Wheel Grinder
Please complete the form below to arrange a tool demonstration for the Dynabrade 52638 4-1/2" (114mm) Dia. Right Angle Depressed Center Wheel Grinder or any of the Dynabrade range of tooling. Alternatively please call us on 01273 468736.
