Description
Product Description of Dynabrade 52864 .4 HP Straight-Line Pencil Grinder
• Tool has integrated collet with 1/4" Collet Insert (01497). Optional 52898 Thread Guard allows easy access to collet cap. With Thread Guard in place, larger diameter accessories may be run by tool. (All accessories must have maximum operating speed of 25,000 RPM).
• High-efficiency rotary vane air motor models are ideal for precision deburring and finishing on a variety of surfaces.
• An ideal tool for use in casting houses, effective on cast parts of aluminum, bronze and brass. Quickly and efficiently removes gates and parting lines in cast parts.
• Adjustable tool speed from 5,000 RPM to 25,000 RPM. Operate tool and adjust speed by simply rotating rear black cover.
• Tactile grip on shaft end allows fingertip control, and alerts operator to rotating collet area. Changing of attachment is achieved with easy, two-wrench maneuver. Unique housing shape allows tool to be held as a traditional Die Grinder.
The Dynabrade 52864 .4 HP Straight-Line Pencil Grinder is a Dynabrade tool within the Pencil Grinder category of tooling range. Spindles of can be used which can also be supplied by DynaShop. A Non-Vacuum tool with a maximum RPM of 25000, a power rating (hp/W) of 0.4 (298) with a weight of 0.56kg.
Parts Manuals for the Dynabrade 52864 .4 HP Straight-Line Pencil Grinder
Find the five digit number for your part(s) in the parts manual below, and click the link to open a new tab where you can add it to your basket. Please note that depending on the age of your tool this may not be the correct parts manual - it should however state the range of serial numbers to which it applies at the top left/right of the first page.
Current Manual
Book a Dynabrade Repair
Vibration & Sound Readings for the Dynabrade 52864 .4 HP Straight-Line Pencil Grinder
Please note – The vibration readings provided for the Dynabrade 52864 .4 HP Straight-Line Pencil Grinder are based on laboratory results in very specific sets of conditions. Vibration levels are dependent on a number of factors that include, among many others; the abrasive being used, the job in hand and operator experience. DynaShop or Dynabrade cannot be held responsible for the consequences of using the listed values for risk assessment, rather than real-world values measured in your own specific application.
| Vibration Level EN1296 (m/sec²) | Uncertainty EN1296 (m/sec²) | Vibration Test Method |
| Under 2.5 | 1.1 | ISO 8662-13 |
| Sound Pressure (dBA) | Sound Power (dBA) |
| 76 | 87 |
