Description
Product Description of Dynabrade 52855 0.1 HP Straight-Line Variable Speed Pencil Grinder
• Dynabrades Variable Speed Pencil Grinder offers precision deburring, finishing and engraving, with easily adjustable speed to suit each application. This is an essential tool for turbine blade manufacturers, tool & die shops, machine shops, investment castings, jewelry, medical implants, composites and more!
• High-Quality Air Line; 1/4" (6 mm) in diameter and 5 feet (1.5 m) in length. Over-hose Assembly; Helps direct air and excess oil away from operator - 12" (305 mm) in length. Variable Speed Flow Control; Adjust your desired speed with dial, up to 60,000 RPM. Unlike roll valves, your speed stays set when turning tool off and on. One Touch Starts Tool at Desired Speed; Handy push-button for simple on/off operation. Tool comes on at same speed as when you shut it off!
• Ergonomic Tactile Grip; Tactile, non-slip grip is insulated for comfortable use. Large Precision Bearings; Ensure longer tool life than competitive models. Spindle Lock Allows Easy Collet Tightening; With thru-hole for quick accessory change. No struggling with two wrenches! Low Collet Run-Out; Run-out of less than .003 minimizes vibration and ensures high-quality cut.
• Model accepts optional collet inserts: 1/16" (51760) and 3/32" (51674).
The Dynabrade 52855 0.1 HP Straight-Line Variable Speed Pencil Grinder is a Dynabrade tool within the Pencil Grinder category of tooling range. Spindles of can be used which can also be supplied by DynaShop. A Non-Vacuum tool with a maximum RPM of 60000, a power rating (hp/W) of 0.1 (75) with a weight of 0.61kg.
Parts Manuals for the Dynabrade 52855 0.1 HP Straight-Line Variable Speed Pencil Grinder
Find the five digit number for your part(s) in the parts manual below, and click the link to open a new tab where you can add it to your basket. Please note that depending on the age of your tool this may not be the correct parts manual - it should however state the range of serial numbers to which it applies at the top left/right of the first page.
Current Manual
Tune-Up Kit
Book a Dynabrade Repair
Vibration & Sound Readings for the Dynabrade 52855 0.1 HP Straight-Line Variable Speed Pencil Grinder
Please note – The vibration readings provided for the Dynabrade 52855 0.1 HP Straight-Line Variable Speed Pencil Grinder are based on laboratory results in very specific sets of conditions. Vibration levels are dependent on a number of factors that include, among many others; the abrasive being used, the job in hand and operator experience. DynaShop or Dynabrade cannot be held responsible for the consequences of using the listed values for risk assessment, rather than real-world values measured in your own specific application.
| Vibration Level EN1296 (m/sec²) | Uncertainty EN1296 (m/sec²) | Vibration Test Method |
| N/A | N/A | N/A |
| Sound Pressure (dBA) | Sound Power (dBA) |
| 67 | 78 |
Would you like this data in an email?
Simply fill out the form below and the vibration data for the Dynabrade 52855 0.1 HP Straight-Line Variable Speed Pencil Grinder will be sent to your email automatically.
On-Site Tool Demonstrations of the Dynabrade 52855 0.1 HP Straight-Line Variable Speed Pencil Grinder
Please complete the form below to arrange a tool demonstration for the Dynabrade 52855 0.1 HP Straight-Line Variable Speed Pencil Grinder or any of the Dynabrade range of tooling. Alternatively please call us on 01273 468736.
